Category：Gas and oil fired boiler series
Product Name: Product Description of Environmentally friendly Hot Gas Stove
One Structural features:
1. Convert coal into gas for combustion (secondary combustion), without emitting black smoke, with a smoke depth of 50-70mg, meeting emission standards.
2. It can save about 5% of production fuel and 10-30% of electricity consumption, achieving energy conservation and consumption reduction.
3. One refueling can take 30-60 minutes, reducing the labor intensity of the operation. Due to the fewer refueling times, the working environment is improved.
4. As gas is a flammable and explosive material, a pre ignition device is added to the design. As long as the operating procedures are followed, it is as safe and reliable as a household gas stove (liquefied gas stove).
5. The fan can be equipped with a variable frequency adjustment controller to control the motor according to the user's requirements, and the power consumption can achieve the desired effect.
6. Each air supply system is equipped with valve control to ensure that adjustments can be made at any time during operation according to the user's requirements for fire usage.
7. Adding a water seal pool to the ash chamber under the grate can achieve safe water sealing. It can also extinguish the slag that falls into the pool, making it easier to clean up the ash. Due to the wet discharge of ash, there is no dust flying, and the operating environment and conditions are significantly improved.
8. There are one to two coking holes on the top of the gas stove, which facilitate coking when coking inside the gas stove.
II technological process
The process flow of this system is: ignite the furnace in the combustion chamber until an open flame appears, then ignite the gas furnace - coal is oxidized, reduced, distilled, and dried in the furnace and mixed with air to produce gas - enters the combustion chamber - the gas is ignited by a flame in the furnace - and begins to burn.
| model | RMQ400 | RMQ500 | RMQ600 | RMQ700 | RMQ800 | RMQ900 | RMQ1000 |
| Inner diameter of furnace (mm) | four hundred | five hundred | six hundred | seven hundred | eight hundred | nine hundred | one thousand |
| Furnace cross-sectional area (㎡) | zero point one two six | zero point one nine six | zero point two eight two | zero point three eight four | zero point five zero two | zero point six three five | zero point seven eight five |
| Heating surface area of water jacket (㎡) | two point seven three | three point four two | four point one | four point seven nine | five point four six | six point one five | six point eight four |
| Applicable coal types | Non adhesive or weakly adhesive smokeless coal, bituminous coal, or coke. The coal quality should meet the requirements of GB9143 | ||||||
| Ash layer height (mm) | 100~200 | 100~200 | 100~200 | 100~200 | 100~200 | 100~200 | 100~200 |
| Particle size of coal (mm) | | | 13~25 | 25~50 | 50~100 | | |
| Coal consumption (kg/h) | 10~20 | 30~40 | 50~60 | 70~80 | 90~100 | 120~140 | 150~180 |
| Gas production (Mm3/h) | 30~60 | 90~120 | 100~180 | 210~240 | 270~300 | 360~420 | 450~540 |
| Gas calorific value (KJ/m3) | 5020~6060 | 5020~6060 | 5020~6060 | 5020~6060 | 5020~6060 | 5020~6060 | 5020~6060 |
| Gas outlet temperature (℃) | 400~550 | 400~550 | 400~550 | 400~550 | 400~550 | 400~550 | 400~550 |
| Coal addition method | Manual | ||||||
| Fan motor power (kw) | two point two | two point two | three | three | four | five point five | seven point five |
| Fan pressure (Pa) | one thousand one hundred and thirty-nine | one thousand one hundred and thirty-nine | one thousand four hundred and thirty-nine | one thousand four hundred and thirty-nine | one thousand six hundred and sixty-eight | two thousand four hundred and ninety-one | two thousand nine hundred and eighty-six |
| Fan flow rate (m/h) | one thousand one hundred and forty-six | one thousand one hundred and forty-six | one thousand five hundred and thirty-nine | one thousand five hundred and thirty-nine | two thousand five hundred and fifty | three thousand two hundred and twelve | five thousand one hundred and thirteen |
| Slag discharge form | Wet and automatic slag discharge | ||||||
